DEAF BONCE AP-M67AN
$449.90
- 6-1/2″ Apocalypse Series Mid-range Car Speakers
- Power Handling:
- Peak: 1200 watts per pair / 600 watts each
- RMS: 600 watts per pair / 300 watts each
- Pressed Paper cone material
- Cloth speaker surround
- 1.75″ CCAW voice coil
- Neodymium magnet motor structure
- Aluminum frame material
- Top-mount Depth: 2.7″
- Cutout Dimensions: 6″
- Impedance: 4 ohm
- Frequency Response: 200 – 14000 Hz
- Sensitivity: 102 dB
- Recommended High-Pass Filter: 150-250 Hz (24dB/octave) / 250-350 Hz (12dB/octave)
- Recommended Low-Pass Filter: 8-12.5 Hz (12dB/octave)
6 in stock
Specifications
| Model | AP-M67AN |
| Type | Midrange |
| Size | 6.5″ |
| Frequency response | 200-14000 Hz |
| Package quantity | Pair |
| Voice coil size | 1.75″ |
| Cone | Paper |
| Magnet | Neodymium |
| Voice coil wire | CCAW |
| Surround | Cloth |
| RMS Power | 300 W |
| MAX Power | 600 W |
| Frame | Alu |
| Impedance | 4 Ohm |
| SPL | 102.00 dB |
| Fs | 125.00 Hz |
| Qts | 0.31 |
| BL | 9.30 |
| Vas | 5.72 L |
| Mounting depth | 2.66″ (67.5 mm) |
| Cut-out dimension | 5.98″ (152.0 mm) |
| Gross weight | 8.99 lb (4.08 kg) |
Additional information
| Weight | 9 lbs |
|---|
