PRV QS400.4

Name: PRV QS400.4
Brand: PRV Audio
SKU: QS400.4
Availability: InStock

$139.00

QS Series amplifiers are all about efficient design capable of full-range frequency response at a great price!

The QS400.4 features a regulated power supply that is able to constantly deliver power and provides an unsurpassed efficiency rate of 80–90% in a small aluminum heatsink.

4 x 100 watts TRUE RMS certified at full range output Digital Class D Brazilian Technology
4 Channel car audio amplifier stable at 2 Ohm gives you the benefit of wiring multiple speakers and dividing the power per channel.
Engineered to be the most efficient full range amplifier so that you can get the most out of your vehicle’s electrical system!
A small footprint and compact chassis make this amplifier easy to install anywhere in the vehicle: 4″ Wide x 5.40″ Length x 2″ Height
2 Channel Bridged – double the power output to your speakers by bridging two channels. Minimum impedance of 4 Ohms per bridged channel at output power of 2 x 200 Watts RMS.

Channels	4 Channel
Rated RMS Power at 14.0 V at 2 Ohm	4x 100 Watts
Rated RMS Power at 14.0 V at 4 Ohm	4x 70 Watts
Bridged Rated RMS Power at 14.0 V at 4 Ohm	2x 200 Watts

2 in stock

SKU: QS400.4 Category: 4 Channel Amplifiers Brand: PRV Audio

Description
Additional information

GENERAL SPECIFICATIONS

Impedance	2 Ohm
Channels	4 Channel
Rated RMS Power at 14.0 V at 2 Ohm	4x 100 Watts RMS
Rated RMS Power at 14.0 V at 4 Ohm	4x 70 Watts RMS
Bridged Rated RMS Power at 14.0 V at 4 Ohm	2x 200 Watts RMS
Average Efficiency	80%
Operating Voltage	9 to 15 Volts
Musical Current Draw	45 A
Minimal Power Wire Input	(OFC) 8 Gauge wires
Built-in Crossover	Fixed HPF & LPF at 90 Hz
Minimal Speaker Wire Output	14 Gauge
Frequency Response(-3dB)	20 – 25,000 Hz
Min. Input Sensitivity for Max. Output	200 mV
Signal Input	2 Pair RCA
Signal to Noise	>90 dB
Protection System	High Temperature / Short circuit on Output
Heat Sink Type	Heavy Duty Cast Aluminum
Dimensions ( Width x Depth x Height )	4.00″ x 5.40″ x 2.00″
Weight	1.18 Lbs

The power rated data are based on equipment from the PRV Audio Group laboratory. Frequency reference of 100Hz to 1kHz with THD+N to ≤1 % in impedances referring to the indicated in each measurement. The electronic components and the manufacturing process can present manufacturing variations, thus leading to a variation in the measurements made. This amplifier is designed to perform on music applications (with speakers), any load test (resistant load) is not recommended.
